Ruckus Networks · Entry-Level+ Stackable Access Switch

RUCKUS ICX 8200

The RUCKUS ICX 8200 is a stackable access switch family with 25GbE uplinks, PoE+++ options for multi-gigabit access points, and Pro AV-tuned variants for low-latency multicast — sized from compact in-room units to high-availability dual-PSU chassis.

Request a Datasheet Request a Quote

20 models

Models

RJ45 Fixed PSU

RJ45 with PoE

Hot-swap Dual PSU

Compact

Fiber

Need help sizing your ICX 8200 deployment?

Our engineers can help you pick the right model and PoE budget for your site.

Talk to an expert

RUCKUS ICX 8200

Models

RJ45 Fixed PSU

ICX8200-24Ports:24× GbEPoE:No PoEUplink:4×25G SFP2824-port switch with 25GbE stacking for future-proofed access

ICX8200-24PPorts:24× GbEPoE:370W PoE+Uplink:4×25G SFP2824-port PoE+ switch for standard AP and endpoint deployments

ICX8200-24PVPro AVPorts:24× GbEPoE:370W PoE+Uplink:4×25G SFP28Pro AV-tuned 24-port PoE switch for low-latency multicast

ICX8200-24ZPPorts:24× Multi-GigPoE:740W PoE+++Uplink:4×25G SFP28Multigigabit PoE+++ switch built for Wi-Fi 6E/7 access points

ICX8200-48Ports:48× GbEPoE:No PoEUplink:4×25G SFP2848-port switch with 25GbE stacking for larger deployments

RJ45 with PoE

ICX8200-48PPorts:48× GbEPoE:370W PoE+Uplink:4×25G SFP2848-port PoE+ switch for campus-wide access deployments

ICX8200-48P-VPro AVPorts:48× GbEPoE:370W PoE+Uplink:4×25G SFP28Pro AV-tuned 48-port PoE switch

ICX8200-48PFPorts:48× GbEPoE:740W PoE+Uplink:4×25G SFP28High-PoE-budget 48-port switch, up to 1480W with dual PSU

ICX8200-48PF-VPro AVPorts:48× GbEPoE:740W PoE+Uplink:4×25G SFP28Pro AV-tuned high-PoE 48-port switch

Hot-swap Dual PSU

ICX8200-48PF2Ports:48× GbEPoE:1480W PoE+Uplink:4×25G SFP28Dual hot-swap PSU 48-port switch for high-availability deployments

ICX8200-48PF2-VPro AVPorts:48× GbEPoE:1480W PoE+Uplink:4×25G SFP28Pro AV-tuned dual-PSU 48-port switch

ICX8200-48ZP2Ports:48× Multi-GigPoE:1480W PoE+++Uplink:4×25G SFP28Dual-PSU multigigabit switch for high-density Wi-Fi 6E/7 rollouts

ICX8200-48ZP2-VPro AVPorts:48× Multi-GigPoE:1480W PoE+++Uplink:4×25G SFP28Pro AV-tuned dual-PSU multigigabit switch

Compact

ICX8200-C08PFPorts:8× GbEPoE:124W PoE+Uplink:2×10G SFP+Compact 8-port PoE switch for in-room deployment

ICX8200-C08PFVPro AVPorts:8× GbEPoE:124W PoE+Uplink:2×10G SFP+Pro AV-tuned compact 8-port PoE switch

ICX8200-C08ZPPorts:8× Multi-GigPoE:240W PoE+++Uplink:2×25G SFP28Compact multigigabit PoE switch for high-performance in-room APs

ICX8200-C08ZP-VPro AVPorts:8× Multi-GigPoE:240W PoE+++Uplink:2×25G SFP28Pro AV-tuned compact multigigabit switch

Fiber

ICX8200-24FPorts:24× 1G SFPPoE:No PoEUplink:4×25G SFP2824-port fiber switch for fiber-fed access layers

ICX8200-24FXPorts:16× 10G SFP+PoE:No PoEUplink:8×25G SFP28High-speed 10G fiber switch for demanding fiber aggregation

ICX8200-48FPorts:48× 1G SFPPoE:No PoEUplink:4×25G SFP2848-port fiber switch for fiber-to-the-room deployments
